Humidification Systems

Overview

Humidification is the process of increasing the amount of moisture in the air. Low relative humidity is not only uncomfortable but is also damaging to equipment and materials. If the atmosphere is too dry, moisture is drawn from surrounding materials within the area such as furniture, textiles, paper, fruit, animals and even people. These negative effects can be prevented by increasing the humidity level. A higher humidity level can also reduce fire risk and static electricity.

Our ultrasonic humidification system is ideal for increasing the level of relative humidity within a room by introducing moisture back into the air without causing wet areas or excessive water drop out.

Ultra fine fogs down to only 1 micron (0.001mm) are possible therefore ensuring the soft plume of water droplets remain in suspension until evaporation takes place. When complemented with our special water valve assembly, the unit becomes a highly efficient self cleaning humidifier.

The heavy duty stainless steel water valve is controlled by the same compressed air supply used to activate the nozzle. A simple on/off signal is required to activate the system and when the signal is removed, the water valve self cleans the nozzle every time by blowing excess water away, significantly reducing lime, salts and chalk build-up.

In large industrial and commercial applications, nozzles can be mounted in the roof space to raise humidity levels without over fogging. Significant advantages may be achieved without reducing visibility and safety. Factories where inflated humidification is needed can be economically improved. The dry fog humidifiers are strategically located to give an even humidity level. Mains water can be used incorporating a water purifier and due to the unique self-cleaning design, there is no risk of blocked nozzles.

Applications

Advantages

  • Close Humidity Control
  • Low energy consumption
  • Low operating costs
  • Less than 5 micron droplets
  • Self-Cleaning Nozzles
  • Non-Drip System
  • Significant cooling effect
  • Saves up to 90% on steam energy
